Cantilever Retaining Wall

This application includes two major calculation steps and provide you a comprehensive calculation report in PDF and in DXF(Autocad):

• Stability evaluation which includes the overturning, bearing, and sliding failure modes.
• Designing the different components of Retaining Wall: stem, heel, toe and key, for bending and shear, under the combined factored loads.

Results:

• Check stability Verticals and Laterals forces.
• Graphic display of forces and pressures acting upon the wall.
• Establish Stem, Heel, Toe and Key thickness by Verifying shear & moment.
• Bearing Capacity Verification.
• Graphic plot moment and shear diagrams to optimize reinforcing bars.
• Graphic plot for required flexural reinforcement to optimize reinforcing bars.
• Complete stability analysis for overturning, sliding, and bearing.
• Graphic plot of Nominal Moment.
• Graphic plot Stress diagrams.
• Graphic plot Neutral axes diagrams.
• Graphic plot for wall elevation with Cutoff Location in Tension side.
• Concrete design of stem, toe, heel, and key.
• Graphic plot for reinforcement distribution
• Ability to create a DXF file containing the reinforcement in details
• Create a comprehensive calculation report containing all calculation details
