WeldUp Pocket

34 metal trade calculators that work with no signal. Offsets, flat patterns, machine settings, iso sketches: the right number, on the job, the second you need it.

A tape, a soapstone, and a number that has to be right the first time.

WeldUp Pocket gathers what a pipefitter, a welder and a fabricator have always worked out in their head or on a scrap of cardboard: the offset, the flat pattern, the saddle, the machine settings. Thirty-four tools, one entry, one answer. Nothing to look up, nothing to wait for.

EVERYTHING WORKS OFFLINE Under a vessel, in a trench, up in the steel: the app never asks for a signal. No account, no ads, no data leaving the phone.

PIPEFITTER • Offset — any angle, center-to-center and the pipe length to cut • Tube bending — where to mark, how much to cut, what the wall takes • Pipe branch template — the saddle wrap, printed at full scale • Iso sketch — draw the run first, dimension it after, get the pipe takeoff and the spool pieces, and export the drawing as a PDF • Custom elbow — the take-out of an elbow cut to an angle the catalog does not carry • Custom reducer — where to cut a stock reducer for the size you are missing • Accessory library — a valve's face-to-face measured once, dropped onto the drawing in one tap • Hydrostatic test — test pressure and water volume • Line weight — pipe, water, insulation • Level — slope and plumb, two full-screen vials, zeroed on the spot

WELDER • Amperage settings — process, material, thickness, joint and position: a 10 A window to dial into the machine • Welding distortion — shrinkage, angular pull, the gap to build in before you weld instead of fighting it after • Gas selection — mix, ISO 14175 class, cylinder color • Flow and purge — flow rate, time, chamber volume • Metallurgical compatibility and weld defect diagnostics • Torch components — TIG and MIG diagrams, tap any part

FABRICATOR • Bend, cone and shell course development • Neutral axis, joint allowances, weight, check circumference • Drilling and tapping — speed, feed, pilot hole, and the drill to pick for any M size

LIBRARY • Material specification — which diameter, which wall, which grade for which job, with the loads to put a number on it • Material traceability — the camera reads the pipe marking (grade, heat number, lot) and files it under the open job • Flange gasket — start from the fluid, not the gasket: first choice, fallbacks, the traps that cost • Flange bolting — how many bolts, what diameter, what length, what wrench: EN 1092-1 and ASME B16.5 • Section weight — square tube, angle, flat, round, at the length you need • Grades, weld and piping symbols, polarity, fitting dimensions, unit converter

BUILT AROUND THE JOB Open a job: everything calculated after that hangs off it. History keeps seven days, one line reopens the tool with the values already in, and a whole job goes out in a single message — text, mail, chat.

MADE FOR WORKING HANDS A keypad sized for a gloved finger, with the fraction bar. Light theme readable in full sun, dark in the shop. Imperial or metric: inches to the sixteenth, a dimension types as "3 1/2", the way it reads on the print.

IN SIX LANGUAGES English, French, Spanish, German, Italian, Polish. Interface, reference sheets and release notes.

HONEST ABOUT WHAT IT IS The values are indicative. They replace neither the applicable codes (ASME, AWS) nor a qualified WPS — they save the ten minutes between the question and the answer. And every result shows where its number comes from.

Made by a welder, for the people who set the steel.
