OpenDXF

3D DXF support is here! View files with 3DFACE entities and Z-axis coordinates in three dimensions — just drag to orbit the model.

OpenDXF is a fast and practical DXF viewer built for iPhone, iPad and Mac devices. Open your drawing files, inspect them easily in the workshop or on-site, and create essential dimensions directly on screen.

Key features:

• Fast DXF file opening and viewing
• Smooth zoom and pan (pinch to zoom)
• Fit-to-screen and easy navigation
• Core dimensioning tools:
  • Parallel dimension
  • Horizontal/Vertical dimension
  • Angular dimension
  • Diameter (Ø) and radius (R) dimension
• Drag-and-place dimension positions and labels -Add notes to drawings -Clean interface optimized for iPhone and iPad OpenDXF is designed for users who need quick drawing checks and pre-production measurement verification.
