MilliDraw - Measure & Draw

Scan or import a reference drawing, calibrate it from a known distance, and add measurements on top. You can now fill the shapes with patterns!

MilliDraw helps you turn real-world measurements into clean 2D drawings on iPad.

Use it when a rough paper sketch, photo, or text message is not clear enough for a workshop, contractor, installer, or CAD handoff.

Common jobs:

• Custom marble, wood, glass, and metal cuts
• Kitchen cabinets and countertop measurements
• Irregular walls, corners, and room shapes
• Site sketches for contractors and installers
• Quick CAD base drawings exported as DXF

What you can do:

• Build scaled drawings from site measurements
• Capture irregular walls, corners, cutouts, and custom shapes
• Work natively in millimeters, centimeters, decimeters, meters, inches, or feet
• Enter exact lengths, angles, radii, and rotations
• Move lines, connected selections, circles, and arcs by exact X or Y distances
• Revise geometry without redrawing the complete plan
• Set independent line colors and weights for new or selected geometry
• Fill supported closed areas with solid color, diagonal hatch, crosshatch, or dots
• Draw freely by default, switch to 90° Lock, or temporarily constrain an active line to one axis
• Close geometry faster with endpoint alignment guides
• Scan or import a reference drawing, calibrate it from a known distance, and draw measurements on top
• Position, rotate, fade, lock, or hide the reference while keeping drawing elements editable above it
• Add freehand notes and movable typed annotations
• Measure from a fresh in-app depth capture on a LiDAR-supported iPad
• Export readable PDFs with line weights, fills, and refined millimeter, circle, and arc dimensions
• Export DXF files for CAD workflows
• Reopen project data from PDFs exported by MilliDraw
• Open the localized in-app Help & Guide for drawing, measurement, annotation, editing, and export
• Work offline without accounts or subscriptions

MilliDraw is intentionally lightweight. It is not a full CAD system. It is for the fast measured drawing you need before the details are forgotten, before you leave the site, or before a custom part is made.
