TubeLoad

Calculate deflection, bending moment, stress, and load capacity for aluminium and steel tubes. Built for film-set riggers, scaffolders, and structural designers.

TubeCalc is a fast structural calculator for aluminium and steel tubes, designed for film-set riggers, grips, scaffolders, and anyone who needs to verify load limits in the field.

Four loading configurations: • Simple — single point load on a simply-supported tube • Two Loads — two independent loads, anywhere along the span • Cantilever — fixed at one end, load at the free end • Boom — overhanging beam with counterweight and adjustable support

Calculates: • Deflection (with L/120 serviceability limit) • Bending moment and bending stress • Maximum safe point load • Shear force and bending moment diagrams • Support reactions

Material library includes 6000-series aluminium alloys (6060, 6061-T6, 6082) and structural steel grades (S235–S420) — both EU and US variants.

Other features: • Adjustable design factor (1:1 to 7:1, or custom) • Metric and imperial units • Save tube presets for quick recall across all calculators • Interactive beam diagrams — drag loads to see live updates • Works offline

Important: TubeCalc is an engineering aid, not a substitute for a qualified structural engineer. Always have rigging verified for safety-critical applications.
