PixelTrace

Browse xLights vendor prop catalogs and view print-ready wiring diagrams. Built by a fellow lightshow enthusiast.

PixelTrace is a free companion app for the xLights community. Browse prop catalogs from popular vendors, view interactive wiring diagrams, and print or export them for easy reference while you push pixels.

BROWSE & SEARCH Search across vendor catalogs by category, vendor, or keyword. Filter by Christmas, Halloween, Singing Faces, and more. The catalog syncs directly from the same vendor library xLights uses — always up to date.

WIRING DIAGRAMS Tap any prop to see a detailed, interactive wiring diagram showing start node, end node, and string lengths. Flip between front and rear views with a tap.

PRINT & EXPORT Export diagrams as print-ready PDFs scaled to letter-size paper. Share diagrams with your crew so everyone can pitch in on wiring day.

FAVORITES Save your go-to props for quick access. No account needed — everything is stored on your device.

BUILT FOR THE COMMUNITY PixelTrace pulls from the open-source xLights vendor registry. Vendors can submit their prop libraries to the xLights GitHub repo and they'll appear automatically.

Free. No ads. No account required. No personal data collected.
