Thermal Gradient Studio

Thermal Gradient Studio is a structured tool for exploring heat transfer through layered constructions. The app helps visualize temperature distribution, thermal resistance, and heat flow using clear interactive charts and organized results.

You can build multi-layer wall assemblies, adjust indoor and outdoor temperatures, define surface convection coefficients, and review calculated U-value, R-value, and heat flux indicators. Interactive gradient views allow you to examine ΔT across each layer and observe how thickness influences performance.

The comparison mode lets you review two assemblies side by side, while the thickness sweep feature provides a visual overview of how insulation changes affect thermal behavior.

Educational sections explain core concepts such as thermal conductivity, resistance, convection, and energy loss in a simple and structured format.

All calculations can be saved to history, edited, or reviewed later. Units, themes, and interface preferences are customizable.

This app is intended for educational and informational use.
