Electrace Heat Loss Calculator

Fast, accurate heat-loss calculations for trace heating. Designed for installers, engineers, and maintenance teams who need reliable numbers on-site.

Electrace — Heat Loss Calculator gives installers, engineers, and maintenance teams fast, accurate heat-loss estimates for trace heating applications. Designed by Electrace Heating Ltd, this tool helps you validate insulation selections, determine watt outputs, and confirm system requirements before installation.

Whether you’re on-site, in the workshop, or preparing a design package, the app delivers engineering-grade results in seconds.

Features

• Accurate heat loss calculations based on pipe OD, insulation material, insulation thickness, ambient conditions, and safety factors • Supports all common pipe materials and DN sizes • Environment presets including indoors, outdoors, exposed, and sheltered • Built-in wind speed and safety factor inputs • Instant results for per-metre loss, system total, and recommended cable wattage • Export options: JSON, CSV, and printable PDF output • Clear warnings and input validation to help prevent design errors • Installer-friendly layout with a simple, clean interface

Why Use This App?

Trace heating performance depends on accurate thermal design. The Electrace Heat Loss Calculator helps you:

• Avoid cable under-sizing or overheating • Validate insulation decisions • Speed up system design and documentation • Improve accuracy for quotations and field engineering • Maintain consistency with Electrace Heating Ltd design practices

Built for Professionals

Developed to support Electrace Heating Ltd engineers, this tool provides reliable, practical results suitable for industrial, commercial, and process applications.

Disclaimer

This tool provides estimated heat-loss values for guidance only. Always verify results against Electrace Heating Ltd design standards, manufacturer data, and actual site conditions before installation.
