MOV Toolkit

This app supports Limitorque SB/SMB size 000-5 actuators. Four primary tools are included:

• Tools, a field shopping list that includes tools and test equipment needed to work on the selected actuator size.
• Hardware, a list of the bolts and fastener sizes in use on the selected actuator size. A bolt size to wrench size conversion, TTC information, and actuator/HBC weights.
• Switches, a configurable switch connection card for use in hooking up switch leads when testing.
• Turns, a calculator that computes milliseconds and inches/degrees of travel per intermittent gear adjustment, and a hand wheel to inches/degrees of travel converter, with total hand wheel turns. Turns requires the stem lead and OAR for the actuator in order to work.
