FindCable

FindCable calculates cable type and size, determines circuit breaker nominal breaking current, and generates single-line diagrams for main distribution or MCC panel power outputs in 3P or 1P 50Hz electrical circuits.

With the ability to easily adjust parameters and see the effects instantly, you can make more informed decisions when selecting the right cables or breakers.

This app allows you to perform quick calculations for a single load or manage multiple projects with up to 50 loads. You can then export the results as a single-line diagram in PDF format and send them via email.

When using the project option, all input parameters are stored locally on your device. The application supports loads with cables up to 300mm².

The calculated cable sizes represent the minimum required, but keep in mind that minimum and maximum short-circuit currents are not yet considered.

FindCable’s results should be used as a reference and verified by an engineer before implementation.
