Interactive Training Diagrams

Features & Capabilities

The Boeing 737 NG Interactive Diagram App is a comprehensive training aid for studying the B737 NG systems. It lets you manipulate Electrical, Fuel, Bleed Air, Hydraulic, Fire Detection and Protection, Flap and Slats, and CPCS to see how each component reacts, and you can simulate emergencies using a checklist to test problem-solving.

It also includes an interactive cockpit poster with component descriptions and integrates with Cockpit Companion diagrams. DISCLAIMER: These diagrams are for reference only and cannot replace formal training.
