Sketchalyze

Sketch and analyze structural systems on the iPad.

In Sketchalyze, Analysis results such as deformations and section forces are visualized instantly, a finite element analysis is performed in the background whenever needed. Features:

• Tabulated and user defined cross sections
• Truss and beam element types
• Line and point loads on beam elements
• Listing of model and result data
• Share models via email and Facebook
• Linear and geometrical nonlinear (load or displacement controlled) analysis
• Load-deflection curves for nonlinear analysis
• Visualization of kinematic modes for unsufficiently constrained systems
• Background image for creating models of structures from photographs or drawings
