Axialmark: 3D CAD Model Viewer

Axialmark brings professional-grade 3D CAD viewing to iOS. Explore complex STEP, STL, GLB, PLY, WRL, OBJ, IGES and other 3D models with Metal-accelerated rendering.

Axialmark is a high-performance 3D CAD and engineering model viewer for iPhone and iPad.

With on-device geometry processing and Apple Metal rendering, Axialmark delivers precise inspection and fluid navigation for STEP assemblies, STL meshes, PLY point clouds, and other 3D engineering models.

Whether you are in the workshop, preparing a client presentation, traveling, or working at your 3D printing desk, Axialmark helps you inspect and present 3D designs wherever you are.

Key Features:

• Precise CAD Geometry Inspect solid and surface models with clear feature edges and Hidden Line Removal (HLR) for technical viewing.

• Metal-Accelerated Rendering Orbit, pan, and zoom through complex models with responsive, high-quality rendering.

• Product Assembly Structure Tree Browse hierarchical assemblies, expand or collapse branches, isolate components, and see selections reflected in the viewport.

• ViewCube and Camera Controls

• Tap or drag the interactive ViewCube for standard orthographic and isometric views.
• Switch between orthographic and perspective projection.
• Use multi-touch orbit, pan, pinch-to-zoom, and Fit All framing.

• Professional Display Styles Choose Shaded, Shaded with Edges, Wireframe, or Hidden Line Removal views. A reference grid supports spatial orientation.

• Model Information Review bounding-box dimensions, triangle and face counts, file size, and unit information.

• Private, On-Device Processing Open models from Files, iCloud Drive, AirDrop, and shared documents. Processing and rendering stay on your device.

Supported Formats:

• STEP / STP / STEPZ / STPZ
• IGES / IGS
• STL, PLY, OBJ
• glTF / GLB
• BREP, XCAF, VRML / WRL

Download Axialmark to inspect, review, and present 3D engineering models on the go.
