NEC 690 Reference

Expanded with 60 NEC sections, 5 in-app calculators, 25 quiz questions, 10 worked examples, inspection checklists, and ampacity tables — fully offline.

NEC 690 Reference is a study and field companion for solar photovoltaic professionals working under the National Electrical Code Articles 690, 691, 705, 706, and 710. Everything is paraphrased educational summary — designed for quick lookups, exam practice, and inspection prep, fully offline.

WHAT IS INSIDE

• 60 NEC section summaries across Articles 690 (PV Systems), 691 (Large-Scale PV), 705 (Interconnection), 706 (Energy Storage), and 710 (Stand-Alone Systems)
• 31 plain-language definitions of NEC terms (PV source circuit, PV output circuit, MPPT, rapid shutdown, AHJ, NRTL, qualified person, listed, labeled, and more)
• 10 step-by-step worked examples with numbers and conclusions: cold-temperature Voc, PV source current sizing, voltage drop, conductor temperature derating, OCPD selection, conduit fill, inverter AC sizing, 120% rule, EGC sizing, breaker selection
• 25 NABCEP-style practice quiz questions with explanations and NEC citations
• 3 inspection checklists (pre-install, mid-install, final inspection) with 16+ checkpoints each, anchored to specific NEC sections
• 4 quick reference tables: standard breaker sizes, copper ampacity (75 / 90 C), aluminum ampacity (75 / 90 C), and copper conductor resistance per 1000 ft
• 13 code-change entries highlighting differences between NEC 2017, 2020, and 2023 for the major solar-related sections

5 IN-APP CALCULATORS

• Cold-Temperature Voc — adjusts module Voc for the lowest expected ambient and reports the maximum string length under the inverter max DC voltage (NEC 690.7)
• PV Source Circuit Current — applies the 1.25 x 1.25 factor for conductor and OCPD sizing (NEC 690.8 and 690.9)
• Voltage Drop — AC single phase, AC three phase, and DC; copper or aluminum; AWG 14 to 4/0
• Conduit Fill — EMT, RMC, and PVC Schedule 40; THWN-2, XHHW-2, and PV Wire; warns when fill exceeds 40 percent
• Breaker Size — selects the next standard NEC 240.6 ampere rating for continuous or non-continuous loads

DESIGNED FOR

• Solar PV installers and electricians
• Electrical engineers and PV designers
• Building inspectors and plan reviewers
• Apprentices and NABCEP candidates studying for certification

IMPORTANT

All content is an original paraphrased educational summary. This app is not a substitute for the official NEC or any certification exam materials. Always consult the latest published NEC and the local Authority Having Jurisdiction for legal requirements.
