CodeCell Dashboard

Stream live 9-axis IMU data from your CodeCell C3 with one-tap CSV export. No cloud, no subscriptions. Code available at https://github.com/maxinjapan/CodecellDashboard

CodeCell Dashboard turns your iPhone or iPad into a live motion sensor telemetry station. Paired with the CodeCell C3 hardware module, it streams, visualises, and exports high-frequency 9-axis IMU data in real time, with no cloud, no subscriptions, no fuss.

Whether you are prototyping a robotics project, characterising a mechanical system, or simply exploring inertial sensing, CodeCell Dashboard gives you professional-grade visualisation and data export tools in a clean, intuitive interface.

HARDWARE REQUIRED

CodeCell Dashboard requires the CodeCell C3 sensor board to function. The app cannot record or display data without an active Bluetooth connection to a CodeCell C3 device.

Get yours at: microbots.io/products/codecell

FEATURES

LIVE 9-AXIS IMU CHARTS Monitor all sensor channels in real time at up to 100 Hz: accelerometer (m/s2), gyroscope (deg/s), magnetometer (uT), and computed orientation (roll, pitch, yaw in degrees). Charts scroll continuously with a 10-second rolling window so you always see the most recent data.

FULL-SCREEN CHART VIEW Tap any sensor card to expand it to full-screen landscape mode for a closer look at your data with an extended 15-second window.

EFFORTLESS BLE PAIRING The app automatically scans for nearby CodeCell C3 devices the moment Bluetooth is ready. Connect with a single tap; no pairing codes or configuration required.

PAUSE AND RESUME Freeze the live stream at any moment to inspect what just happened, then resume without losing buffered data.

CSV EXPORT Export the complete full-resolution data log as a timestamped CSV file, including absolute timestamps and millisecond-accurate elapsed time for every sample. Share directly to Files, iCloud Drive, Google Drive, email, or any other app via the iOS share sheet.

iPHONE AND iPAD SUPPORT Adaptive layout optimised for both iPhone and iPad, making full use of the larger iPad screen.

PRIVACY

CodeCell Dashboard collects no personal information. All sensor data received from the hardware stays entirely on your device. Nothing is transmitted to any server. Data is shared only if you explicitly export it yourself.

DISCLAIMER

CodeCell Dashboard is an independent project and is not sponsored by, affiliated with, or endorsed by Microbots or the CodeCell brand. The CodeCell C3 hardware is a product of Microbots; this application is a third-party companion developed independently.
