IQ | 3D Scan

Capture Your Production Floor Before Cobot Deployment

Plan smarter cobot installations from day one. IQ 3D Scan turns your iPhone or iPad into a portable 3D site survey tool, letting you capture an accurate model of your production floor — machines, conveyors, fixtures, walls, and obstacles — before a Robotiq cobot solution is deployed.

By giving integrators and project teams a true-to-scale digital model of the workspace, IQ 3D Scan removes the guesswork from layout decisions, reach studies, and cell design. Spot interferences early, validate footprints, and align stakeholders around the same view of the actual environment — not a hand sketch.

KEY FEATURES

• LiDAR-powered 3D capture — Use the built-in LiDAR sensor to scan your production area and generate a dimensionally accurate 3D model in minutes. • Whole-environment scanning — Capture machines, work cells, conveyors, pillars, safety fences, and surrounding structures in a single walk-through. • Built for site visits — Lightweight workflow designed to be used on the plant floor during pre-sales visits, feasibility studies, and engineering surveys. • Works offline — Scan on site even when connectivity is absent or spotty. Captures are saved on your device and can be uploaded later when you're back in range. • Secure upload to Robotiq tools — Sign in with your Robotiq account and send scans straight to your projects, where application engineers and integrators can plan cobot placement, reach, and cell layout against the real environment. Scans stay tied to your projects and visible only to authorized team members.

WHO IT'S FOR

• Robotiq distributors and integrators conducting pre-deployment site surveys • Application engineers designing palletizing, machine-tending, or assembly cells • Sales and project teams who need a faithful view of the customer's floor when proposing a cobot solution

WHY IT MATTERS

Traditional site surveys rely on tape measures, photos, hand-drawn layouts, and 2D floor plans that are often years out of date. Critical details get lost, equipment has moved, and surprises show up at install time. IQ 3D Scan replaces that workflow with a single, repeatable scan of the floor as it actually is today — so cell design, reach studies, and integration planning all start from the same accurate model of the real workspace.

REQUIREMENTS

• iPhone or iPad with a LiDAR sensor (iPhone 12 Pro or later, iPad Pro 2020 or later) • A Robotiq account and internet connection required to upload scans to Robotiq IQ (scanning itself works offline and does not require an account)
