electronics filter toolkit Apple

electronics filter toolkit

Passive and Active filter

Features & Capabilities

Design RC, RL, and RLC filters up to 7th order in seconds. Butterworth, Chebyshev, band-pass/reject, Twin-T notch, passive crossovers.

Design RC, RL, and RLC filters (2nd–7th order) with Butterworth & Chebyshev alignments, passive crossovers, RLC band-pass/reject, and Twin-T notch—enter specs to instantly get component values and quick Bode insights in a clean, offline-friendly, dark-mode UI for lab, classroom, and audio/embedded work.

What you can design: -RC & RL filters: low-pass / high-pass, 2nd–7th order -RLC filters: band-pass & band-reject (notch) -Butterworth: maximally flat magnitude -Chebyshev: ripple-tuned sharpness -Twin-T notch: precise mains or tone suppression -Passive crossovers: 2-way/3-way starter calculations

Built for engineers, hobbyist and students, it turns specs into trustworthy parts fast—so you can prototype smarter, learn by tweaking, and move from idea to BOM with confidence.

User Growth & Download Statistics

App
By:
Anas Abubakar
Version:
1.0 Last updated: 2025-11-12
Version code:
879266373
Creation date:
2025-11-12
Compatible devices:
Size:
21.94MB
URLs:
Website ,Privacy policy
Full description:
See detailed description
Source:
Apple Apps Store
Data ingested on:
2026-06-13
Compare stats and ranking:

Contact the developer

Chrome-Stats does not own this Apple app. Please use these information below to contact the Apple app developer.
Developed by:
Anas Abubakar
Apple Apps Store
https://apps.apple.com/id/app/electronics-filter-toolkit/id6754560517
Website:
https://docs.google.com/document/d/e/2PACX-1vStKNte24p44hnXJooW0jImr85IB_W96rzpkMtFBEZ1fXTb-IoeSJUywzMEHPOMjQzIxH9BJyr7zeLX/pub
