Jardineira

Concept:

The app “Jardineira” will convert incoming singing voice to fine monophonic MIDI data using pitchBend. It works as AUv3 effect. Please check out the following system requirements.

System Requirements:

1. AUv3 host which has a flexible capability of MIDI routing (“AUM”, “apeMatrix”, “Loopy Pro”, etc)
2. Headset (Apple’s “EarPods”, for example)
3. 3rd-party instrument that has a functionality of pitchBend.

Scheme:

Voice in -> Jardineira (MIDI out) -> 3rd-party instrument

Usage:

One important calibration

1. Adjust Jardineira’s pitchBend range to the same value as the one of destination instrument.

There are 9 sliders.

1. “channel” means the output’s MIDI channel
2. “audio out” determines whether the input voice is turned on or off (default: OFF)
3. “pitchbend range” determines Jardineira’s internal pitchbend range
4. “transpose” transposes MIDI note.
5. “input gain” means microphone’s input gain in dB.
6. “latency” : the smaller the value, the worse the analysis. this trade-off is inevitable.
7. “envelope follower” determines whether envelope follower works or not (default: ON)
8. “MIDI CC” determines MIDI control change number.
9. “amount” determines how the envelope follower affects MIDI CC value.

Specifications:

Available range: C3 - C6
