Duct Sensor Assistant

Via the Belimo Duct Sensor Assistant App it is possible to extend the range of use and to adapt the configuration individually to application requirements. A Bluetooth® dongle is required for configuration via the Belimo Duct Sensor Assistant App (sold separately, A-22G-A05).

Features: • Communication via Bluetooth BLE • Bluetooth Dongle A-22G-A05 required, which will communicate with the sensor via a Micro-USB-connector • Can be used for the following sensors: 22ADP-.., 22DTH-..5.., 22DTH-..6.., 22DC-..3, 22DTC-.., 22DTM-.., 22DCV-.., 22DCM-.., 22DCK-.., 22UTH-..50X, 22UTH-..60X • Supported languages DE, EN, FR, IT, ES, PT

Configuration options: • Individual configuration of output signals • Setting of different measuring ranges • Additional adjustment of offset values • Parameterization of Live-Zero-Signal (2..10 V etc.) and the system of units • Setting options for display indications • Customized parameterization of traffic-light function (TLF) • Extension of the physical bus address • Store settings on the mobile device and load on other sensors • Representation and output of the differential pressure as a volume flow value
