Medium voltage installations

Features & Capabilities

The most complete tool to support the calculation of high voltage electrical installations.

Free sections:

  • Determination of the characteristics of the equipment: rated voltage (Ur), withstand at industrial frequency (Ud), withstand type of lightning (Up), short-term current (Ik)
  • Sizing of low and medium voltage insulated cables (≤ 30 kV)
  • Calculation criteria for admissible current, voltage drop, short circuit and protection, consideration of different factors for reducing the admissible current: temperature, thermal resistivity of the ground, grouping, sun exposure, etc.
  • Multiple installation methods: tray, buried, under pipe, in the air ...
  • Visualization of protection relay trip curve and MV cable admissible current
  • Protection with transformer limiting fuses
  • Earth fault current calculation (isolated neutral and earth)
  • PE conductor
  • Transformer performance and voltage drop
  • Primary/secondary conversions in voltage and current transformers
  • Secondary voltage of a transformer acoording to switch position
  • Calculation of the transformation center ventilation needs
  • Five safety rules
  • Consult ANSI codes electrical protections
  • Tray sizing
  • Representation of 1 IEC curve
  • Parameter configuration Voltages, frequency, conductivity of the conductor material, temperature MV specific: list type, cable bundle (flat / staggered) Regulation of LV protections
  • Possibility of sharing results

Purchases In-App:

  • Calculation of short circuits and impedances with the maximum and minimum values, type diagram with the following configuration: Network, Transformer, MV line, LV line
  • Selection of voltage and current transformers (protection and measurement), capacitor bank of the transformer, calculation of the number of insulators
  • Protection and adjustment of the transformer overcurrent relay, selectivity with low voltage switch (Ir, Isd, Ii), graph of the actuation curves and identification of characteristic points
  • Calculation of medium voltage line (short line model, single circuit) with conductors: AL1 / ST1A (LA), AL1 / S20SA (LARL), AL3 / ST1A (DA), AL3 (D)
  • Dimensioning and checking of protective and service grounding installation, system configuration, calculation of Howe parameters, step and contact voltages, distance between grounding, single grounding, additional safety measures and results checking
  • Representation of up to 3 IEC curves with different voltage levels
  • Removal of ads with any purchase made

IN NO CASE SHALL THE AUTHOR BE LIABLE FOR ANY DIRECT OR INDIRECT DAMAGES AS A RESULT OF THE CORRECT OR INCORRECT USE OF THE APPLICATION
