RST Decoder

Simple Morse Decoder App for CW Beginner It is a Morse practice App that you can use to check if you are keying the correct code.

This is an App that decodes Morse code input from the microphone. It is a Morse practice App that you can use to check if you are keying the correct code. Signals with good S/N can be decoded correctly, but signals with bad S/N cannot be decoded correctly. Also, the performance will be degraded for extremely slow or fast signals. Usually about 5 to 10 characters are required for speed synchronization of Morse Code. Adjust the input signal so that the peak value changes from level 6 to level 7. Make fine adjustments to each parameter according to the reception status.

[Additional Functions] -In addition to the decoder using BPF, a new decoder using FFT has been added so that it can be switched according to the usage. -AFD (Auto Frequency Detector) function has been added to the decoder using BPF, and BPF can be set automatically by pressing the AFD button. -The decoder using FFT automatically follows the strongest signal in the band by AFD (Auto Frequency Detector) and AGC (Auto Gain Control). You can also hold the AFD / AGC parameters by pressing the Lock button.

• There will be a time lag of about 1 to 2 seconds for AFD tracking.

[Control parameters]

1. Audio Input Level 2.BPF ON/OFF 3.BPF of Center Frequency 4.BPF of Band Width 5.CW Speed Control ON/OFF 6.CW Speed Control Low, Mid1, Mid2 or High 7.Delete All Decoded Text 8.Realtime CW Signal Display 9.Input signal recording / playback function *Japanese/KANA text is not supported.

[Note] Since the signal after BPF is output to the audio output, it can also be used as an AF-CW filter.

[URL of this App working example video] https://youtu.be/Pwp7W4m-m34
