GPS DrivingRecorder Archive

It is an application that records GPS position information and running data such as speed, acceleration, roll, pitch, temperature, humidity, road surface temperature, weather, road surface condition, barometric pressure, setting information for motor sports. The recorded data can be checked on the viewer by combining the running trajectory with information such as speed, acceleration, pitch and roll. For temperature, humidity, and weather, weather information can be acquired and automatically set using the Internet (cancellation option function). The temperature and humidity can be set automatically in cooperation with the SwitchBot thermo-hygrometer (MAC address of the SwitchBot thermo-hygrometer is required). You can edit directly by tapping temperature, humidity, road surface temperature, weather, road surface condition, and barometric pressure.By connecting a GPS logger (such as RaceBox,GL-770M,BU-353N5,DG-PRO1S) via a mock location service (MLS, DroggerGPS), it is possible to record driving trajectories with higher accuracy than the built-in GPS. To select a course, tap Course to display the course selection screen, so select the course (course registration is required in advance).In the course registration, you can select from the shooting record using the course name and the built-in camera, and the image on the smartphone body (the recorded image can be confirmed with the viewer).To register the setting information, tap Parts to display the parts selection screen, so select Parts (part name).By tapping the Parts (part name) added as setting information, you can register / change the setting information (adjustment value, memo) (parts to be added as setting information need to be registered in advance). To register, modify, or delete courses and parts,On the Parts & Course screen, you can register a new course or parts by tapping and . When registering a new course, you can enter the course name, and when registering a new part, you can register the part name, memo, and number of uses. To modify a part, tap the Parts (part name) you want to modify. To modify the course, tap the Course (course name) you want to modify to display the function menu. Select change course name, image display, image selection, or camera shooting.Driving data and setting information can be deleted by swiping left. Courses and parts can be deleted by swiping up on the Parts & Course screen.
①Tap the course, temperature (TEMP), road temperature (ROAD), road surface condition, humidity (RH), barometric pressure (AP), and weather to enter.
　If it is linked with OpenWeatherMAP or SwitchBot thermo-hygrometer, it will be set automatically, so you only need to enter the part to be changed.
②Tap Set offset (Since the current smartphone installation status is recorded, it is OK only at the time of installation)
③To use the mock location service, tap the (start the pseudo location service).
③To use the mock location service, tap "Start LocationService" in the menu.
④Tap the REC button to start measurement.
⑤Tap the STOP button to end the measurement.
⑥Tap the driving data to display the driving data confirmation screen.On the confirmation screen, graphs of temperature, humidity, road surface temperature, weather, road surface condition, barometric pressure, setting information, running locus, speed, acceleration, pitch and roll are displayed. Various graphs can be pinched and traced.
