DCDC Converters Design

Say goodbye to complicated procedures and the requirement for external software to simulate your designed converter and embrace a more simplified approach.

Check out what our app brings to the table – Buck, Boost, and Buck-Boost converters for both continuous and discontinuous operation. It's all neatly split into two main sections:
- Usual design:
- Resulting the passive components (R, L, C) and the duty cycle (%).

- Reverse engineering:
- Resulting the Power Output (W), Ripples (%) and duty cycle (%).

In both of these, you can tap into the advanced zone and explore some exciting activities:
- Advanced Calculations:
- Critical Inductance
- Currents flowing through Input-Output, Switches, and Diodes
- Current-voltage variation at the passive components.

In addiction, you can access some specials features as:
- Snubber design
- E-Core Inductor design
- Simulation for both operation modes.

And the best part? We've got your back with a bunch of helpful info right in the app. Navigate through a comprehensive help section that provides insights into app features and the foundational principles of power electronics theories.
